Yokogawa GS610 SourceMeter Unit – Precision Source & Measure Instrument (Pre-Owned)

Description

Features

• usb storage
• v/i curve tracer
• arbitrary waveform
• waveform reproduction

Specifications

• Source and sink operation up to 110 V/3.2 A (four-quadrant operation)
• Basic accuracy: ±0.02% (DC voltage generation)
• Sweep output at up to 100-µ intervals
• Comes with abundant sweep patterns (linear, logarithmic, and arbitrary)
• Stores up to 65535 points of source measure data in the internal memory
• Remote control and FTP using Web server function (Optional)
• Easy file operation with the USB storage function
• The output and measurement resolutions are 5.5 digits.
• Voltage generation/measurement range: 200 mV to 110 V
• Current generation/measurement range: 20 µA to 3.2 A

Maximum output current

• ±3.2 A & (at an output voltage of ±12 V or less)
• ±2 A (at an output voltage of ±30 V or less)
• ±1 A (at an output voltage of ±60 V or less)
• ±0.5 A (at an output voltage of ±110 V or less)

Operation modes

• Voltage generation/current measurement (VS/IM);
• Voltage generation/voltage measurement (VS/VM);
• Current generation/voltage measurement (IS/VM);
• Current generation/current measurement (IS/IM);
• Voltage generation (VS);
• Current generation (IS);
• Resistance measurement (VS/IM or IS/VM)

The GS610 is a highly accurate and highly functional programmable voltage/current source that incorporates voltage/current generation and measurement functions. The maximum output voltage and current are 110 V and 3.2 A, respectively. Evaluation of over a wide range of basic electrical characteristics is possible because the GS610 can operate as a current source or a current sink.
