Description
Features
- Five instruments in one (IV Source, IVR Measure)
- 100V, 3A, 100W
- Source and sync (4-quadrant) operation
- 0.012% basic measure accuracy
- 6 1/2-digit resolution
- 2-, 4-, and 6-wire remote V-source and measure sensing
- 1700 readings/second at 4 1/2 digits via GPIB
- Pass/Fail comparator for fast sorting/binning
- Programmable DIO port for automation/handler/prober control
- Standard SCPI GPIB, RS-232 and Keithley Trigger Link interfaces
Applications
- Discrete semiconductor devices
- Passive devices
- Transient suppression devices
- ICs, RF ICs, MMICs
- Laser diodes, laser diode modules, LEDs, photodetectors
- Circuit protection devices (TVS, MOV, Fuses, etc.)
- Airbags
- Connectors, switches, relays
- High brightness LEDs (DC and pulse)
- Leakage tests
- Low voltage/resistances tests
- LIV tests
- IDDQ tests
- I-V characterization tests
- Isolation and trace resistance tests
- Temperature coefficient tests
- Forward voltage, reverse breakdown, leakage current tests
- DC parametric test
- DC power source tests
- HIPOT tests
- Photovoltaic cell efficiency (source and sync) tests
- Dielectric withstanding tests
The Keithley 2425 100V/3A/100W SourceMeter SMU Instrument is designed specifically for test applications that demand tightly coupled sourcing and measurement. The 2425-C provides precision voltage and current sourcing as well as measurement capabilities; it is both a highly stable DC power source and a true instrument-grade 6 1/2-digit multimeter. The power source characteristics include low noise, precision, and readback. The multimeter capabilities include high repeatability and low noise. The result is a compact, single-channel, DC parametric tester. In operation, this instrument can act as a voltage source, a current source, a voltage meter, a current meter, and an ohmmeter. Manufacturers of components and modules for the communications, semiconductor, computer, automotive, and medical industries will find the 2425-C invaluable for a wide range of characterization and production test applications.
