New Tektronix FCA3100 High-Performance Frequency Counter

Description

Features:

• 300 MHz
• 2 Channels
• 50 ps Single-shot Time Resolution
• 12 Digit/s Frequency Resolution
• 0.001° Phase Resolution
• 3 mV or better Voltage Resolution
• Optional 5×10–8 High-stability Oven Time Base

Additional Functions and Features:

• Automated Measurements: Frequency, Period, Ratio, Time Interval, Time Interval Error, Pulse Width, Rise/Fall Time, Phase Angle, Duty Cycle, Maximum Voltage, Minimum Voltage, Peak-to-Peak Voltage
• Multi-parameter Display
• Trend Plot Mode
• Measurement Statistics Mode
• Histogram Mode
• Allan Deviation
• Zero Dead-time Frequency/Period Measurements
• Continuous Data Streaming over USB/GPIB Bus during Measurement (FCA3100 Series)
• Programmable Pulse Output from 0.5 Hz to 50 MHz

With industry-leading frequency and time resolution, the FCA Series comes standard with deep internal memory and a fast data transfer rate of 250k Samples/s to internal memory. In addition, the multi-parameter display shows auxiliary measurements alongside your main measurement to provide you with the results you need at a glance. With the industry’s most comprehensive analysis modes, including measurement statistics, histograms, and trend plots, you have the tools you need to quickly and accurately analyze your signal.
