Tektronix FCA3020 Frequency Counter – Refurbished & Verified

Description

Features:

Timer/Counter/Analyzer, 300MHz/20GHz, 100 ps, Std Timebase

• Max Frequency: 20 GHz
• Time Resolution: 100 ps
• Frequency Resolution: 12 digit
• Up to 3 Input Channels
• 3-year Warranty
• 12 Digit/s Frequency Resolution
• 0.001° Phase Resolution
• 3 mV or better Voltage Resolution
• Optional 5×10–8 High-stability Oven Time Base
• 250k Sample/s Data Transfer Rate to Internal Memory (Up to 3.75M samples stored)
• Up to 15k Sample/s Data Transfer Rate over USB/GPIB Bus (Block mode)
• Up to 650 Individually Triggered Measurements/s
• Automated Measurements: Frequency, Period, Ratio, Time Interval, Time Interval Error, Pulse Width, Rise/Fall Time, Phase Angle, Duty Cycle, Maximum Voltage, Minimum Voltage, Peak-to-Peak Voltage

The FCA3020 Timer/Counter/Analyzer pack many different functions into one feature-rich instrument. With the industry-leading frequency and time resolution, the FCA3020 comes standard with deep internal memory and a fast data transfer rate of 250k Samples/s to internal memory. In addition, the multi-parameter display shows auxiliary measurements alongside your main measurement to provide you with the results you need at a glance. With the industry’s most comprehensive analysis modes, including measurement statistics, histograms, and trend plots, you have the tools you need to quickly and accurately analyze your signal.
