Keithley 7067 PXI Switch Module – Used & Tested

Description

Features:

• 4-Wire Scanner Card with Screw Terminal Connections
• Channels per card: 10
• <1μV contact potential
• 4-pole Form A relays
• Quick disconnect screw terminal connections

Four-wire or Kelvin connections are generally made to minimize errors created by I-R drops in the cabling and interconnects of a test system.

Each channel of the Model 7067 has two generalpurpose source contacts that switch currents up to 350mA, as well as two high quality contacts (<1μV contact potential) for dry switching of voltage to the sensing circuit. The Model 7067 is well-suited to precision resistance measurements as required in temperature coefficient testing. Other applications include remote sensing of voltage source outputs and bridge measurements.
