Agilent DSA90404A Digital Sampling Oscilloscope – Legacy High-Speed Model, Used

Description

Features:

• 4 GHz (upgradeable to 13 GHz)
• 4 analog channels
• Capture a longer signal trace with up to 1 Gpts memory and 20 GSa/s sample rate
• Get superior measurement accuracy with a noise floor of 0.79 mVrms at 50 mV/div and deep jitter analysis capability
• Make it easier to compensate for probe, fixture, and channel effects with hardware accelerated de-embedding
• Increase scope’s usability with software applications for compliance, debug, and analysis
• Get measurement automation with the user-defined application

What’s included:

• 50 Mpts memory
• High speed serial data analysis
• EZJIT Complete jitter analysis software
• EZJIT Plus jitter analysis software and EZJIT jitter analysis software
• USB optical mouse
• USB keyboard and stylus pen
• User’s quick-start guide
• Detachable accessory pouch
• Local power cord
• E2655B probe deskew and performance verification kit
• Two 54855-67604 BNC-compatible to precision 3.5 mm (f) adapters
• High-performance calibration cable

*The image is for reference only. See product specification for details.
