Agilent 8514B Microwave Test Set – Used

Description

Additional Features:

• Frequency range: 45 MHz to 20 GHz
• Separate reference channel for each incident port
• Built-in electronic switch
• 3.5 mm connectors

The Agilent 8514B S-Parameter Test Set is available for the Agilent 8510C network analyzer for broadband coaxial measurements from 45 MHz to 20 GHz. The Agilent 8514B test set has an architecture that develops a separate reference channel for each incident port. RF switching is done with a built-in electronic switch. For active device measurements, the test set includes the ability to apply DC bias (external) to the test port center conductors. Also available are two 90 dB step attenuators, which allow control of the port 1 and port 2 signal levels.
