Description
Additional Features:
- Supports Dual and triple-band mobile phones on 900/1800 MHz, 900/1900 MHz, 900/1800/1900 MHz
- Impedance: 50 Ohm
- VSWR: < 1.3
- RF input/output: TNC-type, female
- Internal reference frequency: 13 MHz
- Frequency error: < 1 ppm
- Enables accurate and rapid fault identification
- Separates faulty and no-fault-found (NFF) mobile phones to maximise revenues
- Provides improved specifications RF power level accuracy < 1 dB
- Assures intuitive operation and AUTOTEST features to minimise training requirements
- Delivers remote operation and management via a standard PC
The Willtek 4107S tester supports GSM 900/1800/1900, dual-band and triple-band key measurements:
- RX level
- RX qual
- Asynchronous mode
- MS power
- BER/FER
- MS sensitivity
- Phase error
- Frequency error
- Burst shape
- Burst length
- Burst edge failure indicator
The Willtek 4107S is dedicated to service centres and repair depots. The 4107S comes with improved power level accuracy of 1.0 dB, and provides a burst edge failure indicator, asynchronous test mode and remote control operation.
With its remote control capability, the Willtek 4107S can be managed via a PC using the SCPI command set. This supports special test routines or interactive programs for use with a PC. It is also possible to write user-defined test sequences that, for example, cover the full range of GSM channels.
