Description
Weller WAD101N 122F’ to 1022F’ Digital Shop Air Hot Air Station
The WAD101 is a microprocessor controlled hot air station equipped with a HAP1 hot air pencil for use on circuits using small surface mounted components. It uses compressed air or gas from an external source, the delivery volume controlled manually from a pressure regulator. The unit’s flexibility is further increased by its ability to use all other Weller tools of sufficient rating (except vacuum desoldering tools) upto a max rating of 80 watts. The station can identify which tool is in use and automatically calibrate itself for that tool.
Features:
- WAD 101 HOT AIR STATION 120V W. HAP1 USA
- WAD101 includes: HAP1 hot air pencil, PH60 stand and sponge
- Air flow is adjustable using knob on the side of the power unit
- Compact design, ideal for soldering, desoldering, rework SMT components
- Uses fast acting shop air or compressed nitrogen
- Air flow is actuated by a finger switch on the hot air pencil
- Full range of hot air nozzles is available
- ESD safe to protect sensitive components
Specifications:
- Wattage: 100 W
- Desoldering Pencil(s): HAP1
- Temperature Range: 122° F to 1022° F
- Voltage: 120 V/24 V
- Dimensions: 6.5″ x 5.3″ x 4.0″ (166 x 134 x 101mm)
- Power input: 105 W
- Air volume: 5 – 10 l/min
- Temperature range: hot air 150° F – 999° F (50° C – 550° C)
- Accuracy: ± 86° F (30° C)
- Supplied Tip(s): 0058727821
- Air Flow Volume: 1 l/min – 6 l/min
- Pump Type: Compressed Air
