Wavetek 8502A RF Power Meter – Pre-Owned

Description

Features:

• Frequency Range: 30 MHz to 40 GHz depending on detectors (see PEAK POWER SENSOR specifications)
• Power Range
• Pulse: -20 dBm to +20 dBm
• CW: -40 dBm to +20 dBm
• (See sensor specifications)
• Time Base Range: 1.2 ns/div to 20 ms/div (12 ns to 200 ms time window), using either the Data Entry Keyboard or the Control Knob.
• Resolution: 0.1 ns
• Trigger Delay Range: 0 to 200 ms using either the Data Entry Keyboard or the Control Knob.
• Resolution: 0.1 ns
• Triggering Modes
• Internal: -10 dBm to +16 dBm
• External (BNC): TTL levels, Maximum PRF 1 MHz
• Markers: Up to 4 markers/channel plus a Reference Power Level cursor
• Graph Display Mode: Plots the outline of the detected pulse on the electroluminscent display
• Input Channels
• 8501A: Single Channel
• 8502A: Dual Channel
• Auxiliary Outputs/Inputs (BNC)
• Monitor: Provides a voltage proportional to the detected RF envelope.  Risetime is typically 20 ns, output impedance is nominally 50W
• Analog Output: Provides a voltage proportional to detected power.  Scale Factor is 100 mV/dB
• Trigger Input: TTL
• RF Blanking: TTL open collector low during zeroing.  Used to control power source
• Voltage Proportional to Freq (V / GHz): Allows direct entry of frequency from RF power sources equipped with a V µ F output
• GPIB Interface

RF Peak Power Meter 30 MHz to 40 GHz
