Teledyne LeCroy LW420 Arbitrary Waveform Generator – Used, Fully Operational

Description

Additional Features:

• Waveforms
• Sine, 1 Hz – 100 MHz
• Square, 1 Hz – 50 MHz
• Triangle, 1 Hz – 25 MHz
• Ramp, 1 Hz – 25 MHz
• Pulse, (period) 20 ns – maximum memory
• DC
• Standard Functions
• Sine, Square, Triangle, Ramp, Pulse, DC
• Equation Editor
• Waveform (array) Math
• Waveform import from digital oscilloscope or floppy disk
• Waveform Feature Time Resolution: 100 ps
• Available Memory: 256k/channel standard
• Minimum Segment Length: 64 pts
• Maximum Segment Length: Up to available memory
• Number of Links: 512 for 256k memory, 2048 for 1M memory

The LeCroy LW420 Arbitrary Waveform generator is an ideal source of pulse width modulated (PWM) signals commonly used in power, industrial control, and automotive electronics systems.
The 1 Megabyte memory supports long test waveforms where the duty cycle of a pulsed waveform can be varied over a wide range without loss of signal continuity.

Dynamically Stepping Duty Cycle From 1% To 99%.
