Tektronix VITS201 TV Signal Generator – Field-Tested Equipment

Description

Additional Features:

• Digital Composite Signal Generation
• CCIR, EBU, UK National ITS
• Operates in the Presence of Sound in Syncs
• Four External ITS Inputs
• Source Identification
• Program Line Sync and Burst Regeneration
• Loss of Program Input Modes:
  • External Input to Program Out
  • Internal Generator to Program Out
  • Program Line Bypass
• User Programmable Text Generator Provides:
  • Message in Program Line Vertical Interval
  • Message in Active Picture Area for Loss of Program Input Modes
• User Programs for:
  • Insertion of Internal, External, and Source Identification Signals
  • Loss of Program Input Modes Text Insertion
• All User Program Settings Saved in Nonvolatile Storage
• Monitor Output
• Remote Control

Applications:

• VITS Insertion for Broadcast Video Applications

The VITS201 is a low cost, high quality ITS generator and inserter/deleter with features found only in the most expensive transmission grade ITS inserters. In addition to a solid basic generator/inserter unit, the VITS201 provides loss of program continuity modes, multiple inputs for external data insertion, source identification, a text generator for message insertion and a versatile programmer with nonvolatile memory storage for setting up the unit’s operation and loss of program modes.
