Description
Additional Features:
- Bandwidth: 40 MHz
- Channels: 2
- Sample Rate: 500MS/s
- Monochrome LCD Display
- Record Length: 2.5K points
- Vertical Resolution: 8-bits
- Vertical Sensitivity: 2 mV to 5 V/div on all models with calibrated fine adjustment
- Removable Data Storage via Front Panel USB Port
- Seamless PC Connectivity via USB Device Port, with OpenChoice® and NI SignalExpress® PC Software
- Advanced Triggers Including Pulse Width Trigger and Line-selectable Video Trigger
- FFT Standard
- 11 Automatic Measurements
- Multiple Language User Interface and Context-sensitive Help
- Direct Print to all PictBridge® Compatible Printers via USB Device Port
Applications:
- Design and Debug
- Education and Training
- Manufacturing Test and Quality Control
- Service and Repair
The TDS1001B Digital Storage Oscilloscope delivers an unbeatable combination of performance and ease-of-use at a price you can afford. With a 40 MHz bandwidth and 500MS/s maximum sample rate, no other color digital storage oscilloscope offers as much bandwidth and sample rate for the price.
The TDS1001B oscilloscopes provide accurate real-time acquisition up to their full bandwidth, the same record length at all time base settings, advanced triggers to isolate signals of interest, and 11 standard automatic measurements on all models. Their Fast Fourier Transform (FFT) and waveform add, subtract, and multiply math functions allow you to analyze, characterize and troubleshoot circuits.
