Tektronix MDO3104 Mixed-Domain Oscilloscope – Used, Fully Functional

Description

Features:

• Mixed Domain Oscilloscope with (4) 1 GHz analog channels, and (1) 1 GHz spectrum analyzer input
• The Ultimate 6-in-1 Integrated Oscilloscope, Completely Customizable and Fully Upgradeable
• FastAcq™ high-speed waveform capture rate finds elusive signal anomalies quickly
• Wave Inspector® Controls provide easy navigation and automated search of waveform data
• 33 automated measurements and waveform histograms for simplified waveform analysis
• TekVPI® probe interface directly supports active, differential, and current probes for automatic scaling and units
• 9 in. (229 mm) WVGA widescreen color display
• Small footprint and lightweight – Only 5.8 in. (147 mm) deep and 9.2 lb. (4.2 kg)

Oscilloscope

• Bandwidth: 1 GHz
• 4 analog channels
• Sample Rate: 5 GS/s
• 10 M record length on all channels
• >280,000 wfm/s maximum waveform capture rate

Spectrum Analyzer

• Frequency range: Standard: 9 kHz – oscilloscope bandwidth
• Optional: 9 kHz – 3 GHz
• Ultra-wide capture bandwidth up to 3 GHz

Logic Analyzer

• 16 digital channels
• 10 M record length on all channels
• 121.2 ps timing resolution

Today’s integrated designs need an oscilloscope that is just as integrated – such as the MDO3000 Mixed Domain Oscilloscope (MDO) Series. It is the ultimate 6-in-1 integrated oscilloscope that includes an integrated spectrum analyzer, arbitrary function generator, logic analyzer, protocol analyzer, and digital voltmeter/counter. The MDO3000 is completely customizable and fully upgradeable. Add the instruments and performance you need now – or later.
