Tektronix FG501 Signal Generator – Pre-Owned

Description

Additional Features:

• Frequency: 0.01 Hz to 1 MHz in decade steps
• Output Max.: 20 Vp-p into high impedance, 10 V into 50 Ω (SN < B130000: 15/7.5 V)
• Offset Max.: ±7.5 Vp-p into high impedance, 5 V into 50 Ω (SN < B130000: 5/2.5 V)
• Signals: sine, square, triangle, ramp, pulse
• Voltage controlled frequency input (1000:1 ratio)
• Triggering
• Variable phase control
• Symmetry variable from 5—95%
• Internal sweep generator, 3 decades, lin/log

The Tektronix FG501 is a general-purpose, low frequency function generator producing low distortion sine,square,triangle,pulse, and ramp waveforms.Frequency is selectable from .001 to 1 MHz (switched in decade steps). An external VCF input permits controlling the output frequency from external voltage source.Frequency sweep up to 1000:1 ratio may be accomplished by applying a voltage ramp to the VCF input. Output amplitudes of 15 Vp-p open circuit and 7.5 V into 50-ohms can be obtained.
