Tektronix DPO71254C High-Performance Oscilloscope – Used & Calibrated

Description

Features:

• 12.5 GHz
• 50 GS/s
• 10 MS
• 4 Channels
• Uncompromised Bandwidth – Up to 33 GHz analog bandwidth and rise time as fast as 9 ps enables measurement on the latest high-speed serial standards
• True 33 GHz Real-time Analog Bandwidth on 2 Channels with 33 GHz Models
• Industry-leading Sample Rate and Timing Resolution:

-100 GS/s on 2 Channels (33, 25, 20, 16, and 12.5 GHz models)

• Four-channel Simultaneous Performance:

-Up to 23 GHz Bandwidth
-Up to 50 GS/s Real-time Sample Rate
-Up to 250 Megasample Record Length with MultiView Zoom™ Feature for Quick Navigation
-Fastest Waveform Capture Rate with >300,000 wfms/s Maximum per Channel

• Superior Signal Integrity and Excellent Signal-to-Noise Ratio – Observe the truest representation of your waveform
• Pinpoint® Triggering – Minimize time spent trying to acquire problem signals for efficient troubleshooting and shortened debug time
• Visual Trigger – Precisely qualify triggers and find unique events in complex waveforms
• 6.25 Gb/s Real-time Serial Trigger – Assures triggering on the first instance of a specified NRZ or 8b/10b pattern to allow isolation of pattern-dependent effects
• Search & Mark – Provides waveform or serial bus pattern matching and software triggers for signals of interest
• Automated Serial Triggering and Decode Options for 8b10b Encoded Serial Data, I2C, SPI, RS-232/422/485/UART, USB 2.0, and MIPI® D-PHY
• P7500 TriMode™ Probing System – Perfectly matched signal connectivity
• Application Support for High-speed Serial Industry Standards, wideband RF, Power Supplies, and Memory – Enables standard-specific certification, measurement automation, and ease of use

Applications:

• Design Verification including Signal Integrity, Jitter, and Timing Analysis
• Design Characterization for High-speed, Sophisticated Designs
• Certification Testing of Serial Data Streams for Industry Standards
• Memory Bus Analysis and Debug
• Prototype Turn-on and Power Supply Verification
• Research and Investigation of Transient Phenomena
• Production Testing of Complex Systems
• Spectral Analysis of Transient or Wide-bandwidth RF Signals

The Tektronix DPO71254C is a digital Oscilloscope.

The image is for reference only. See product specification for details.
