Tektronix DPO4102B-L Digital Oscilloscope – Certified Used

Description

Features:

• Bandwidth: 1 GHz
• Channels: 2
• Rise Time: 350 ps
• Sample Rate: 5/2.5 GS/s
• Record Length: 5M
• Input coupling: AC, DC
• Input impedance: 1 MΩ ±1%, 50 Ω ±1%
• Vertical resolution: 8 bits (11 bits with Hi Res)
• DC gain accuracy: ±1.5%, derated at 0.10%/°C above 30 °C
• Channel-to-channel isolation: Any two channels at equal vertical scale ≥100:1 at ≤100 MHz and ≥30:1 at >100 MHz up to the rated bandwidth
• Power consumption: 250W Maximum
• >340,000 wfm/s maximum waveform capture rate
• Suite of advanced triggers
• Wave Inspector® controls provide easy navigation and automated search of waveform data
• 42 automated measurements, and FFT analysis for simplified waveform analysis
• TekVPI® probe interface supports active, differential, and current probes for automatic scaling and units
• 10.4 in. (264 mm) bright XGA color display

The Tektronix DPO4102B-L is a 1 GHz, 5/2.5 GS/s on 1/2 channels, 5M record length, 2-channel Digital Phosphor Oscilloscope.
