Description
Features:
- 2 ports
- Frequency range: 100 kHz – 26.5 GHz
- Supports scattering, differential, time domain parameter measurements and more
- Effective for determining Q factor, bandwidth and insertion loss of a filter
- Five sweep types: linear frequency, log frequency, power sweep, CW-time and segment sweep
- Types of calibration: Response, enhanced response, TRL and more
- Supports bias tees
- Interface: LAN, USB Device, USB Host(USB-GPIB)
- Remote control: SCPI/Labview/IVI based on USB-TMC/VXI-11/Socket/Telnet/WebServer
- 12.1-inch touch screen
The SIGLENT SNA5000A series of Vector Network Analyzers have a frequency range up to 26.5 GHz, and support 2/4-port scattering-parameter, differential-parameter, and time-domain parameter measurements.
The SNA5000A series of VNAs are effective instrumentation for determining the Q-factor, bandwidth and insertion loss of a filter. They feature impedance conversion, movement of measurement plane, limit testing, ripple test, fixture simulation and adapter removal/insertion adjustments. The SNA5000A have five sweep types: Linear-Frequency mode, Log-Frequency mode, Power-Sweep mode, CW-Time mode and Segment-Sweep mode. These also support scattering-parameter correction of SOLT, SOLR, TRL, Response and Enhanced Response for increased flexibility in R&D and manufacturing applications.
