Siglent SDM4065A 6½-Digit Precision Multimeter – High-Accuracy Bench DMM, New

Description

Features:

• 6.5-digit benchtop multimeter
• DC voltage and current
• True-RMS AC voltage and current
• Capacitance measurement, continuity test, diode test, frequency measurement, period measurement, and temperature measurement
• Up to 50k readings per second of measurement speed
• 4 display modes: numerical, bar meter, trend chart and histogram
• 256 MB Nand Flash, supports storage of various types of files such as readings, images, configuration files
• Support standard SCPI remote control commands
• Equipped with EasyDMM-X host computer control and sampling software
• Communications interface: USB Device (optional USB-GPIB adapter), USB Host, and LAN

6 1/2 Digit Benchtop Digital Multimeter

The SDM4065A is a 6½-digit digital multimeter, with outstanding measurement accuracy and a touch screen. It is a product designed for high-precision, multifunctional, and automatic measurement needs.

Trend Chart

• Display a data trend over a period of time
• Use the measurement range of the current gear as the vertical scale range of the trend chart
• Continuously adjust the vertical scale based on the range of existing measurement data
• Enter the range of the vertical scale manually

Histogram

• Display the distribution situation of the measurement data
• Current measured value
• Maximum number of samples
• Total number of samples
• Total number of columns

Data Logging

• Logging Sources include AC/DC Voltage, AC/DC Current, Resistance, Capacitance, Frequency, Period, Temperature
• Sample Interval of 1 ms to 3600 s
• Log to Memory: up to 2,000,000 points
• Log to File: up to 360,000,000 points
• Duration and delay up to 100 hours each

Statistics and Limits

• Statistic functions include Max, Min, Average, Span, Std Dev, and Samples
• Samples shows the maximum value of current measurement
• Limits function is available to prompt signals beyond ranges according to the upper and lower parameters
• Limits measurement reading outside the range is displayed in red

Bar Meter

• One of four display modes including numerical, trend chart, and histogram
• Default mode uses the measurement range of the current gear as the scale range of the bar chart
• User may also enter the scale range of the bar chart manually
