Siglent SDG810 Arbitrary Waveform Generator – New, Compact Design

Description

Features:

• 1 channel / 10 MHz bandwidth
• 125 MSa/s sampling rate
• 14-bit vertical resolution
• 5 standard waveforms and 46 built-in arbitrary waveforms (including DC)
• Complete modulation functions: AM, DSB-AM, FM, PM, FSK, ASK, PWM, linear/logarithmic sweep, and burst
• Innovative EasyPulse technology can output pulses with low jitter and quick rising/falling edges
• Standard interfaces: USB Device, USB Host, supports U-Disk storage
• 10 nonvolatile storage spaces for arbitrary waveforms
• Can be seamlessly connected to a SIGLENT Digital Storage Oscilloscope
• Includes EasyWave, the powerful arbitrary waveform editing software

The Siglent SDG800 function/arbitrary waveform generator has a sample rate of 125 MSa/s and is available in a 10MHz or 30MHz bandwidth. The SDG800 is powered with SIGLENT’s EasyPulse technology which produces low jitter and fast rising/falling edges. It does this without being affected by frequency, even at low duty cycle settings, providing the user with a wide range of pulse widths and transition times. This results in a much more versatile generator than other similar DDS designs.
