Description
Features:
- Frequency range: DC to 26.5 GHz
- Measurement range: -24 dBm to +26 dBm
- Connector type: 3.5 mm
- Turns FSMR receivers into precision power meters with a wide dynamic range from -115 dBm to +30 dBm
- Developed especially for level calibration using the R&S FSMR measuring receiver
- Acts as highly accurate reference for determining the absolute power level
- Remotely controlled from the R&S FSMR, R&S NRX or any Windows PC via USB
The R&S NRP-Z27/-Z37 power sensor modules turn the R&S FSMR measuring receivers into precision power meters with a wide dynamic range from -115 dBm to +30 dBm.
The R&S NRP-Z27/-Z37 power sensor modules were developed especially for level calibration using the R&S FSMR measuring receiver. These sensors act as highly accurate references for determining the absolute power level. Together with the excellent linearity of the R&S FSMR, this enables precise power calibration over the entire level range of the measuring receiver. Using an integrated power splitter, the power is fed to the integrated R&S NRP-Z27/-Z37 thermal power sensor module and simultaneously to the measuring receiver via a phase-stable cable.
Like all other power sensors in the R&S NRP family, the power sensor modules are fully self-contained power meters that are remotely controlled from the R&S FSMR, R&S NRX or any Windows PC via USB.
*The image is for reference only. See product specification for details.
