Description
Features:
- Frequency range from 9 kHz up to 40 GHz
- Wide dynamic range of up to 140 dB
- Short sweep times, e.g. 4 ms for 401 points
- High temperature stability of typ. 0.01 dB/°C
- Wide power sweep range of 98 dB
- Wide range of IF bandwidths from 1 Hz to 10 MHz
- Manual and automatic calibration
- Large, high-resolution 12.1″ screen
- Touchscreen user interface
- Two ports
Specifications:
- 40 GHz
The R&S ZNB40 from R&S is a mid range vector netwok analyzer with two or four test ports for the frequency range from 100 kHz to 40 GHz. It has a dynamic range of 135 dB which makes it possible to perform precise measurements on wideband DUTs or components whose behavior at low frequencies is especially important. The analyzer has a large 12.1 inches touch screen inteface which makes it easy to control and review test results. The ports on the R&S 20 have 2.92 mm Male connectors.
