Rohde & Schwarz FSW8 Signal and Spectrum Analyzer – Certified Used

Description

Additional Features:

• Low phase noise of –137 dBc (1 Hz) at 10 kHz offset (1 GHz carrier)
• –88 dBc dynamic range (with noise cancellation) for WCDMA ACLR measurements
• Up to 2 GHz analysis bandwidth
• < 0.4 dB total measurement uncertainty up to 8 GHz
• Real-time analysis up to 160 MHz bandwidth
• High-resolution 12.1″ (31 cm) touchscreen for convenient operation
• Multiple measurement applications can be run and displayed in parallel

Supported Technologies:

• WCDMA/HSPA/HSPA+
• 3GPP LTE
• GSM/EGPRS/EDGE Evolution/VAMOS
• CDMA2000® 1xEV-DO
• CDMA2000® 1xRTT
• TD-SCDMA
• GSM-R
• TETRA
• cdmaOne
• DECT
• WLAN IEEE 802.11 a/b/g/j/p/n/ac
• ZigBee™ IEEE 802.15.4
• RFID
• WRAN IEEE 802.22
• WWAN IEEE 802.20
• DVB-H
• ISDB-T 1 Seg
• CMMB
• DVB-T
• DVB-T2
• ISDB-T
• AM
• FM
• DVB-S
• DVB-S2
• DOCSIS 3.1

Featuring a low displayed average noise level (DANL) of typ. –159 dBm (1 Hz) at 2 GHz and –150 dBm (1 Hz) at 25 GHz without using a preamplifier, the R&S FSW measures spurious emissions quickly and reliably over a wide frequency range. DANL can be further improved by up to 13 dB by means of the analyzer’s switch-selected noise cancellation. Users can thus identify even the smallest of spurious emissions that were previously hidden in the noise floor, and effectively optimize transmit systems.
