Rohde & Schwarz FSP3 Spectrum Analyzer – Pre-Owned

Description

Additional Features:

• Frequency range: 9 kHz to 3 GHz
• Resolution bandwidth: 1 Hz to 10 MHz
• Displayed average noise level: -155 dBm (1 Hz)
• Phase noise: -113 dB (1 Hz) at 10 kHz
• Additional filters: Channel filters from 100 Hz to 5 MHz and RRC filters, FFT filters from 1 Hz to 30 kHz, EMI bandwidths and quasi-peak detector
• Measurement functions for TOI, MC ACP(R), OBW, CCDF, APD, etc
• Measurement applications for cellular standards and general purpose, e.g. phase noise, noise figure, etc.
• DANL typ.: -155 dBm (1 Hz) w/o preamp
• Phase-noise typ.: -113 dBc/Hz @ 10 kHz offset, CF 500 MHz
• Phase-noise typ.: – 145 dBc/Hz @ 10 MHz offset, CF 500 MHz
• TOI typ.: 10 dBm
• 1-dB-compression point: 0 dBm
• 0.5 dB total level uncertainty up to 3.6 GHz
• <0.2 dB linearity error down to -70 dB
• IF digitizer 12 bit 32 MHz (20.4 MHz IF)
• IQ memory 2×128 ksamples
• 2.5ms sweep time in frequency domain
• 1 µs sweep time in time domain
• Up to 70 remote measurements/s via GPIB
• Up to 80 manual measurements/s (screen update)

Supported Technologies

• WCDMA/HSPA/HSPA+
• GSM/EGPRS//EDGE Evolution/VAMOS
• CDMA2000® 1xEV-DO
• CDMA2000® 1xRTT
• TD-SCDMA
• GSM-R
• cdmaOne
• DECT
• WiMAX IEEE 802.16e-2005 and IEEE 802.16-2004
• Bluetooth® (Basic Rate)
• LXI
• AM
• FM

The ideal partner for both development and production, featuring good level measurement uncertainty, as well as excellent RF characteristics. The R&S FSP3 incorporates proven technology to enable best performance, reliability and ease of service. The Rohde & Schwarz FSP3 Spectrum Analyzer is capable of testing spurious emissions stipulated in the GSM specifications and has a firmware to allow adjacent-channel power (ACP) measurement to the W-CDMA/third-generation partnership project (3GPP).

This measurement is implemented in the Rohde & Schwarz FSP3 by automatic test routines which make all necessary settings, measurements and filtering. The electronic attenuator for a spectrum analyzer increases the availability for use in production and allows a number of switching operations in a wear-and-tear-free setting range of 30 dB in 5 dB steps.
