Description
Additional Features:
- Frequency range: 9 kHz to 26.5 GHz
- Compliant with CISPR 16-1-1 Ed. 3.1
- Preselection with integrated 20 dB preamplifier
- Resolution bandwidths in line with CISPR and optionally in decade steps from 10 Hz to 1 MHz (MIL STD-461, DO-160)
- Ultrafast time domain scan (option) or conventional stepped frequency scan
- Realtime spectrum analysis with up to 40 MHz span for detailed investigation of disturbances (option)
- Time domain display with high resolution (50 µs)
- Automatic test routines
- IF analysis (option)
- Certification measurements
- Standard-compliant EMI measurements in spectrum analyzer mode
The R&S ESR26 is an EMI test receiver for the frequency range from 10 Hz to 26.5 GHz and complies with the CISPR 16-1-1 standard. It measures electromagnetic disturbances with the conventional stepped frequency scan or – at an extremely high speed – with an FFT-based time domain scan. At the same time, the R&S ESR functions as a full-featured, powerful signal and spectrum analyzer for lab applications. Featuring realtime spectrum analysis capability with a wide range of diagnostic tools, the test receiver also enables detailed analysis of disturbance signals and their history. The R&S ESR comes with clearly structured menus and an intuitive touchscreen, making it very easy to operate in any mode.
