Rigol DG1022 Function and Arbitrary Waveform Generator – Secondhand

Description

Additional Features:

• Maximum Output Frequency: 20 MHz (5 MHz square wave)
• Output Channels: 2
• Sample Rate: 100 MSa/s
• Arbitrary Waveform Length: CH1: 2 pts – 4kpts; CH2: 2pts – 1kpts
• Resolution: 1 μHz
• Amplitude: CH1: 2 mVpp ~ 10 Vpp(50 Ω),4 mV ~ 20 Vpp(High Z); CH2: 2 mVpp ~ 3 Vpp(50 Ω),4 mV ~ 6 Vpp(High Z)
• Vertical Resolution: CH1: 14 bits; CH2: 10 bits
• Connectivity: USB Host, USB Device
• Monochrome LCD display
• Adopt advanced DDS technology; dual channel output; 100 MSa/s sampling rate; 14 bits vertical resolution
• Output 5 standard waveforms; built-in 48 arbitrary waveforms
• Abundant modulation functions: AM, FM, PM and FSK
• Provide linear/logarithm sweep and burst
• Abundant output and input interfaces: waveform output; synchronous signal output, external modulation source, external clock reference (10 MHz) input, external trigger input
• Channel coupling and channel copy
• Built-in high precision and wide band counter, the measurement range: 100 mHz to 200 MHz (single channel)
• Standard configuration interfaces: USB Device & USB Host
• Seamlessly interconnect with DS1000 series digital oscilloscope
• Powerful arbitrary waveform editing software (UltraWave)
• Support remote control by commands

Applications:

• Analog Sensor
• Practical Environment Signals
• Circuit Function Test
• IC Chip Test

The Rigol DG1022 function/arbitrary waveform generator uses Direct Digital Synthesis (DDS) technology, which enables to generate stable, high-precision, pure and low distortion signals.
