R3754B Advantest Vector Network Analyzer – Refurbished VNA System

Description

Features:

• High throughput Wide dynamic range Program sweeping function MS-DOS format disk Auto offset correction Error correction function 6.5-in TFT color Display w/ brightness Controler Marker function Limit line Data save/recall

Specifications:

• Frequency Range: 10KHz to 150MHz Frequency Resolution: 0.1 Hz Frequency Accuracy: ±5 ppm Output connector: Type BNC female, 50 Ohms Insertion loss: 6 dB Power Resolution: 0.1dB Output Accuracy: 0.5dB Output Impedance: 50ohms Number of Receiver Channels: 1Ch Maximum Dynamic Range: 130dB Sweep Range: 0.1dB Display Resolution: 640 X 480 dots Display Indicator: 6.5 inch color TFT liquid-cyrstal display Operating temperature: 0 to 40 deg C Non-operating temperature: -20 to 60 deg C Power Supply: AC 100 to 120V, AC 220 to 240V at 50/60 Hz Power consumption: 200 VA or less Dimensions: Approx. 424 W X 177 H X 300 D mm Mass: 12 kg or less

The Advantest R3754B is the 150 MHz vector network analyzer, which has been designed based on a concept “an optimum tool for each application”. The R3754B has achieved high throughput such as 50 micro s/points high-speed measurement at a resolution bandwidth (RBW) of 15 kHz, 127 dB (RBW 1 kHz) wide dynamic-range measurement, and two-device simultaneous measurement with two-channel/four-trace display.
