Description
Features:
- 200 MHz Bandwidth
- 4 Channels
- Up to 4 GS/s sample rate
- Long Memory – up to 20 Mpts
- 10.1” capacitive touch screen display
- Powerful, Deep Toolbox
- 16 Digital Channel MSO option
Included with Standard Configurations:
- 10x Passive Probe (Total of 1 Per Channel)
- 1 Micro SD card (Installed)
- Micro SD card adapter
- Protective Front Cover
- Getting Started Guide
- Commercial NIST Traceable Calibration with Certificate
- Power Cable for the Destination Country
- 3-year Warranty
The WaveSurfer 3024z is a 200MHz, four channel Oscilloscopes. It provides the most advanced user interface of any Oscilloscope sold presently through a 10.1″ capacitive touch screen. It promotes true versatility with 20 Mpts of memory, multi-instrument capabilities, a powerful deep toolbox and Mixed Signal capability as an option.
MAUI – Most Advanced User Interface
- Designed for Touch
- Built for Simplicity
- Made to Solve
Advanced Anomaly Detection
- Fast Waveform Update
- History Mode – Waveform Playback
- WaveScan – Search and Find
Multi-Instrument Capabilities
- Protocol Analysis – Serial Trigger and Decode
- Waveform Generation – Built-in Function Generator
- Digital Voltmeter and Frequency Counter
Future Proof
- Upgradeable Bandwidth
Superior User Experience
MAUI is the most advanced oscilloscope user interface. It is designed for touch, built for simplicity, and made to solve.
Biggest Touch Display
A large capacitive touch screen enables accessible and responsive touch operation. The 10.1” display is 30% larger than competitive offerings, providing more waveform viewing area.
Advanced Anomaly Detection
A fast waveform update rate, used in conjunction with history mode, WaveScan, sequence mode, and mask testing facilitates outstanding waveform anomaly detection.
Powerful, Deep Toolbox
The standard collection of math, measurement, debug, and documentation tools provides unsurpassed analysis capabilities.
