Description
Features:
- DC POWER SUPPLY, 0-35V, 0-30A
- Performance Characteristics of the PAN 35-30A
- Form Factor Benchtop
- No. of Outputs 1 o/p
- Output 1 Max. power 1050 Watts
- Output 1/Range 1 Max. Current 30 A (0 V to 35 V)
- Voltage Ripple and Noise 0.5 mV
- Current Ripple and Noise 5 mA
- Load Regulation, Voltage 1 mV
- Load Regulation, Current 5 mA
- Line Regulation, Voltage 1 mV
- Line Regulation, Current 3 mA
- Remote Sensing Measurement Yes
- Multiple Unit Combinations Parallel,Series
- Overvoltage Protection Yes
- Overcurrent Protection Yes
- Over-temperature Protection Yes
- Local Lockout No
- Self test No
The PAN-A Series is a high-performance, highly reliable DC power supply unit featuring regulated variable voltage. These units are suitable for use in a range of fields including research and development, quality control, and production. The PAN-A series DC Power Supplies
PAN-A Series consists of a pre-regulator using FETs and a Series regulator using power transistors, providing the high-quality output characteristic of the latter as well as the low power-source harmonic distortion of choke input type phase control. To achieve the high reliability and safety, components of sufficient derating and long-proven mounting techniques are used throughout. All models are carefully designed and furnished with over voltage protection (OVP) and various safety functions.
