Keysight N9917A Cable and Antenna Analyzer – Previously Owned

Description

Additional Features:

• Cable and Antenna Analyzer (CAT), Vector Network Analyzer (VNA)
• Frequency range: 30 kHz to 18 GHz
• VNA dynamic range: 100 dB to 9 GHz, 90 dB to 18 GHz
• CAT:  Distance-to-fault, return loss, cable loss
• VNA:  S11, S21, S22, S12, magnitude and phase
• Spectrum Analyzer: 5 kHz to 18 GHz
• ± 0.5 dB amplitude accuracy, full band, over full temperature range of -10 to +55°C (14 to 131°F)
• Spur-free dynamic range: ≥ 105 dB
• Full-band tracking generator
• Independent source, vector voltmeter (VVM), power sensor and built-in measurements
• RF source: 30 kHz to 18 GHz, CW, CW coupled, and tracking
• VVM: 30 kHz to 14 GHz, compare phase and electrical length
• Power measurements with USB sensor: 9 kHz to 24 GHz (sensor dependent)
• Built-in power meter: 5 kHz to 18 GHz

The Agilent N9917A FieldFox 18 GHz RF Combination Analyzer’s base function is a cable and antenna analyzer and it can be configured to include a spectrum and network analyzer. FieldFox can be ordered with additional capabilities: power meter, independent signal generator, vector voltmeter, interference analyzer, variable DC source, and built-in GPS receiver.
