Description
Additional Features:
- Cable and Antenna Analyzer (CAT), Vector Network Analyzer (VNA)
- Frequency range: 30 kHz to 6.5 GHz
- Dynamic range: 100 dB
- CAT: Distance-to-fault, return loss, cable loss
- VNA: S11, S21, S22, S12, magnitude and phase
- Spectrum Analyzer: 5 kHz to 6.5 GHz
- ± 0.5 dB amplitude accuracy, full band, over full temperature range of -10 to +55°C (14 to 131°F)
- Spur-free dynamic range: ≥ 105 dB
- Full-band tracking generator
- Independent source, vector voltmeter (VVM), power sensor and built-in measurements
- RF source: 30 kHz to 6.5 GHz, CW, CW coupled, and tracking
- VVM: 30 kHz to 6.5 GHz, compare phase and electrical length
- Power measurements with USB sensor: 9 kHz to 24 GHz (sensor dependent)
The Agilent N9914A FieldFox 6.5 GHz RF Combination Analyzer’s base function is a cable and antenna analyzer and it can be configured to include a spectrum and network analyzer. FieldFox can be ordered with additional capabilities: power meter, independent signal generator, vector voltmeter, interference analyzer, variable DC source, and built-in GPS receiver.
