Keysight N5183B MXG Microwave Analog Signal Generator – Refurbished & Guaranteed

Description

Features

• Frequency Options: 13, 20, 31.8, 40 GHz
• Output Power @1 GHz: +23 dBm
• Phase Noise @1 GHz (20 kHz offset): -130 dBc/Hz
• Frequency Switching (Typical): ≤ 600 μs
• Harmonics @1 GHz: < -40 dBc
• Non-Harmonics @1 GHz: -72 dBc
• Sweep Mode: List, Step
• Frequency Modulation-Maximum Deviation @1 GHz: 4 MHz
• Frequency Modulation-Rate @100 kHz Deviation: DC to 7 MHz
• Phase Modulation-Maximum Deviation: 0.5 to 64 rad
• Phase Modulation-Maximum Deviation in High-BW Mode: 0.05 to 6.4 rad
• Amplitude Modulation-Maximum Depth: 100%
• Amplitude Modulation-Rate: 0 to 100 kHz
• Analog: Yes

The N5183B is a 40 GHz rf generator from Agilent Keysight HP.
