Keysight EXR2MSO Logic Analysis Probe – New, High-Speed Digital Signal Capture

Description

Features:

Correlate analog and digital domains synchronously using Mixed Signal Oscilloscope (MSO) capability:

• Use symbols to quickly interpret waveforms
• Use digital channels for protocol trigger and decode (I²C, SPI, RS-232, JTAG, and more)
• Combine with oscilloscope channels to trigger across up to 24 channels simultaneously

EXR2MSO is a Keysight Infiniium EXR-Series oscilloscope post-purchase upgrade option that integrates 16-channel digital logic analysis capability (including an N2756A probe) on any Infiniium EXR-Series oscilloscope.You do not need to send the scope in to add this upgrade option. EXR-Series scopes are fully post-purchase upgradeable, enabling 8 tools in one chassis. Additional Logic Channel Specifications:

• Minimum Detectable Pulse: 2 ns
• Maximum Toggle Rate: >200 MHz
