Keysight E4991A RF Impedance Analyzer – 1 MHz to 3 GHz, Refurbished

Description

Keysight Agilent HP E4991A Features:

• Basic accuracy
  • +/- 0.8 % basic accuracy
• Sweep parameters
  • Frequency: 1 MHz to 3 GHz
  • Oscillator level: Up to 1 dBm/0.5 Vrms/10 mArms
  • DC bias level (Option E4991A-001): +/- 40V or +/- 50 mA
• More features
  • Windows-styled user interface
  • Built-in VBA programming function
  • Data transfer through LAN interface
• Versatile measurement options
  • Dielectric/magnetic material measurement (Option E4991A-002)
  • Reliable on-wafer measurement (Option E4991A-010)
  • Temperature characteristic measurement (Option E4991A-007)

The Keysight Agilent HP E4991A RF impedance/material analyzer offers ultimate impedance measurement performance and powerful built in analysis function. It will provide innovations in R&D of components and circuit designers who evaluate components in the range of 3 GHz. The Keysight Agilent HP E4991A uses an RF-IV technique, as opposed to the reflection measurement technique, for more accurate impedance measurement over wide impedance range. Basic impedance accuracy is +/-0.8%. High Q accuracy enables low-loss component analysis. The internal synthesizer sweeps frequency from 1 MHz to 3 GHz with 1 mHz resolution.
