Keysight E2655C Test Fixture – Brand New

Description

Features:

• E2655C Probe deskew and Performance Verification Kit
• Includes adapters SMA (m) to SMA (m), SMA (m) to BNC (f), and BNC (m) to SMA (m); 50 Ω SMA terminator; and deskew fixture

A probe deskew and performance verification kit for use with InfiniiMax probes. The E2655C is a replacement of the E2655B. The E2655B is discontinued, but it will be supported until March 2018.

The kit contains the following parts:

• SMA (male) to SMA (male) adaptor
• SMA (male) to BNC (female) adaptor
• BNC (male) to SMA (male) adaptor
• 50 Ω SMA Terminator
• De-skew Fixture

The E2655C Performance Verification and Deskew Fixture can be used to calibrate and verify the performance of the following probes:

• InfiniiMax l (1130B, 1131B, 1132B, 1134B)
• InfiniiMax ll (1168B, 1169B)
• InfiniiMax lll+ probe amplifiers with <13 GHz bandwidth
• InfiniiMax Ultra series probe amplifiers with <13 GHz bandwidth
• N2750/1/2A Differential Probes

You can use the N2787A 3D probe positioner to properly position the probe during the deskew/PV procedure. It is recommended for sophisticated probe head positioning or when using probe heads such as the browser probe head to hold the browser in place.
