Description
Features:
- Available in 2-, 4-, and 8-channel configurations
- Phase synchronous tuning for MIMO measurements up to 8-channels
- Independent channel tuning for LTE-Advanced Carrier Aggregation and simultaneous uplink and downlink measurements
- Analysis bandwidth: Wide range of choices with 40 MHz maximum
- Error vector magnitude: Better than -43 dBm to -47 dBm depending on signal types
- Displayed average noise level (DANL): -158 dBm/Hz
- Third-order intermodulation (TOI) distortion: +12 dBm
- Third-order dynamic range: <-70 dBc
The N7109A is a 2-, 4- or 8-ch RF signal analyzer that leverages the multi-channel and MIMO measurement capabilities of the industry-leading Keysight 89600 VSA software. The N7109A enables fast, informative measurements of WLAN, WiMAX and LTE devices that range from 2×2 to 4×4 to 8×8 channels
The N7109A is implemented in a compact modular measurement platform. You can configure a system with one, two or four N7130A two-channel receiver modules that provide 40 MHz analysis bandwidth from 20 MHz to 6 GHz. Each channel includes a built-in preamp and multiple fixed pre-selectors, which enable and optimize off-the-air measurements. Additionally, each channel can be tuned independently to measure multiple Component Carriers for LTE-Advanced Carrier Aggregation, including MIMO carriers, or to simultaneously measure uplink/downlink signals.
