Description
Features:
- Quad 4-channel multiplexers
- DC to 1.5 GHz, 75 Ohm
- High isolation, low VSWR
- 30V, 0.5A, 10W switching
- 75 Ohm mini SMB connectors
The Keysight 34942A RF multiplexer module for the 34980A Multifunction Switch/Measure Unit offers bi-directional switching broadband signals. High channel isolation ensures quality dynamic range measurements with your oscilloscope, spectrum analyzer, or other instrumentation.
The RF multiplexers are configured as four independent 1×4 RF multiplexers on a single module. Individual multiplexers are isolated from each other and the Mainframe chassis to prevent ground loops. Multiple banks can be cascaded together to create an even larger multiplexer – up to 97 cascaded RF channels in a single 34980A Mainframe.
