Keithley 263 Multifunction Calibrator – Used, Fully Functional

$0.00

Calibrations

Clear

Quantity

SKU: N/A Category: Calibrator Oth Brand: Keithley

Description

Additional Features:

Coulombs Range: 20pC – 20uC
Coulombs res: 0.5fC – 500 pC
5.5 digits LED display
O/p connctr: 2-lug triaxial co
Max. Common Mode V:350Vpk
Easy pushbutton operation
Secondary calibration standard
Switch up to 200V

Specifications:

Form Factor Benchtop
DC Volts Minimum Range 200 mV
DC Volts Maximum Range 20 V
DC Volts No. of Ranges 3 QTY
DC Volts Range Steps 1/10/100
DC Volts Minimum Resolution 5 uV
DC Volts Maximum Resolution 500 uV
DC Volts Basic 1 yr accuracy 0.0175 %
DC Current Minimum Range 2 pA
DC Current Maximum Range 20 mA
DC Current No. of Ranges 11 QTY
DC Current Range Steps 1/10/100
DC Current Minimum Resolution 0.00005 pA
DC Current Maximum Resolution 500 nA
DC Current Basic 1 yr accuracy 0.15 %
Resistance Minimum Range 1 kOhm
Resistance Maximum Range 100000 MOhm
Resistance No. of Ranges 9 QTY
Resistance Range Steps 1/10/100
Resistance Basic 1 yr accuracy 0.40 %

Explore more from our collection.

Additional information

Calibrations	NIST Traceable, NIST Traceable with Full Data, ISO IEC 17025 Accredited
