Description
Additional Features:
- Bandwidth: 16 GH
- Input Channels: 4
- Rise Time: 27.5 ps
- 50 GS/s Real-time Sample Rate
- Record Length: 20M
- Fastest Waveform Capture Rate with >300,000 wfms/s Maximum per Channel
- Digital Serial Analyzer Model with Dedicated Configuration for High Speed Serial Design and Compliance Testing
- Enhanced Bandwidth to the Probe Tip Extended to Support Multiple Bandwidth Steps for Advanced Signal Integrity.
- Pinpoint Triggering, with over 1400 Combinations to Address Virtually Any Triggering Situation
- Unique Serial Pattern Triggering up to 3.125 Gb/s and 8b/10b Standard Protocol Triggering for Isolation of Pattern-dependent Effects
- Serial Data Analysis and Compliance for PCI Express, Serial ATA, FB-DIMM, SAS, Fibre Channel, IEEE1394b, RapidIO, XAUI, HDMI, DVI, Ethernet, USB 2.0
- Most Popular Jitter and Timing Measurement and Analysis Package
- 12.1in Largest XGA Touch Screen Display in the Industry
- MyScope Custom Windows Enhance Productivity
- Right-Mouse-Click Menus for Exceptional Efficiency
- OpenChoice Software with Microsoft Windows XP OS Enables Built-in Networking and Extended Analysis
The DSA71604 oscilloscopes are the new generation of real-time digital phosphor oscilloscopes and are the industry’s best solution to the challenging signal integrity issues faced by designers verifying, characterizing, debugging and testing sophisticated electronic designs. The specialized DSA71604 provides a complete and dedicated solution to address the challenges of high-speed serial designs.
