Fluke DP120 Used Differential Voltage Probe

Description

Additional features:

• Input: Probes with shrouded banana probe tip
• Probe length: 1.5 meter (60 inch)
• Maximum Input Voltage to Ground: 600V RMS CAT III per IEC 1010-2-031 / 1000Vrms CAT II, per IEC 1010-2-031
• Maximum Differential Voltage: 1000V DC or1000Vrms or 1200V (DC + ACpeak)
• Output Cable: Safety designed 0.5m (5ft) BNC Cable
• Attenuation: 200x and 20x
• Bandwidth: DC to 20 MHz (-3 dB)
• Accuracy: ±2.5%
• Rise time: 17.5 ns
• CMRR: 200x: @ 60 Hz > 80dB, @ 1 MHz > 50 dB 20x: @ 60 Hz > 70dB, @ 1 MHz > 40 dB
• Battery type: Alkaline 9 volt, NEDA, IEC6LR61
• Battery life: 8-hour operation, 400-hour stand by
