Description
Features:
- Short-term accuracy to ± 0.01 °C; one-year drift < ± 0.01 °C
- Accredited NVLAP calibration optional
- Flexible PTFE and silicone coated fast-response models
- Rugged polished stainless steel sheaths
Specifications:
- Resistance – Nominal 10,000 ? at 25 °C
- Range – 0 °C to 100 °C
- Calibration – R vs. T table with 0.1 °C increments, interpolation equation furnished
- Calibration uncertainty – Table and equation are accurate to ±0.01 °C
- Drift – Better than ±0.01 °C per year
The 5611T-D is an especially versatile PTFE coated thermistor probe. With a PTFE encapsulated tip that is just 3 mm (0.12 in) in diameter and a PTFE coating that makes it impervious to most liquids, the PTFE Probe is handy for measuring in a wide variety of applications, including bio-pharmaceuticals. It’s even immersible to nearly 20 feet and flexible enough that you could roll it up into a ball in your hand if you wanted to! The 5611T-D thermistor bead is encapsulated in a Mylar sleeve that is encapsulated inside a PTFE sleeve. The PTFE sleeve is then melted around the PTFE-insulated cable, forming a moisture-proof seal.
