Description
Features
- High test voltages up to 10kV with Insulation Resistance to 500GOhm
- Polarization Index (PI) measurement
- Dielectric Absorption Ratio (DAR) measurement
- EnerSave™ limits test duration to 10 seconds to save energy
- Complete with built-in heavy duty carrying case with cover, test leads, alligator clips, and 8 x C batteries
Specifications
- Insulation Resistance: 800kΩ to 500GΩ ( Autoranging )
- Resolution: 1kΩ
- Basic Accuracy: ±5%
- Test Voltages: 500VDC to 10kVDC (adjustable in 500V steps)
- Preset Buttons: 1kV, 2.5kV, 5kV, 10kV
- Polarization Index: Yes
- Dielectric Absorption Ratio: Yes
- Voltage Output Warning: Yes
- Automatic Discharge: Yes
- Dimensions: 13×10.2×6.3″ (330x260x160mm)
- Weight: 7.9lbs (3.6kg)
The MG500 is a digital high voltage insulation tester that tests voltage up to 10kV and measures insulation resistance to 500GOhm. The MG500 has a CAT III 300 Volt safety rating. This product is complete with a year warranty, built-in heavy duty carrying case with cover, test leads, alligator clips, and 8 x C batteries.
