Description
Features
- Range: 44 lbs, 20kg, 196 Newtons (±0.5% accuracy)
- Ideal for a wide variety of applications in the electronics, automotive, chemical, plastics and machinery industries
- Reversible display and fast/slow response mode
- Exclusive load cell measurement transducer
- Overrange, low battery and advanced function indication
- Zero Adjust push-button and Peak Hold switch
- Complete with hook adaptor for tension/compression adaptors, 5″ extension rod, 6 AA batteries and carrying case
Specifications
- Range: 44lbs, 20kg, 196 Newtons
- Basic Accuracy (23°C): ±(0.5%)
- Resolution: 0.01lbs, .01kg, 0.05 Newtons
- Overload capacity: 30kg
- Update Rate: Fast mode 0.2 secs; Slow mode 0.6 secs
- Full scale deflection: 2.00mm
- Transducer Type: Load cell
- Dimensions/Weight: 8.5×3.5×1.8″ (215x90x45mm)/ 1.4 lbs (650g)
The 475044 is a High Capacity Force Gauge with a 5 digit LCD display and peak hold. Exclusive load cell measurement transducer. Over-range, low battery and advanced function indicators. 20kg/44.1 lbs/196.1 Newtons measurement capacity. Selectable fast/slow response times. Basic accuracy of 0.5%. Display reverses to match viewing angle. Complete with tension rod, carrying case and 4 adapters (flathead, cone, chisel and hook for tension), and 6 AA batteries.
