Description
Features:
- Auto/Manual ranging pen-style multimeter
- Large 2000 count high contrast LCD display
- Built-in Non-Contact Voltage (NCV) detection with visible and audible alarm
- Data Hold, Range Hold, Maximum Hold, Auto Power Off
- Overrange and low battery indication
- Ergonomic housing with easy one-hand operation rotary function dial
- Complete with test leads (one built-in tip and one remote with cable), two alligator clips, and 2 AAA batteries
Specifications:
- DC Voltage: 200mV, 2, 20, 200, 600V
- AC Voltage: 200mV, 2, 20, 200, 600V
- DC Current: 20mA, 200mA
- AC Current: 20mA, 200mA
- Resistance: 200, 2k, 20k, 200k, 2M, 20MΩ
- Non-Contact Voltage (NCV): >110VAC
- Logic Test: 0 to 1.5V (Green LED), 1.5 to 3.5V (LED off), 3.5 to 5V (Red LED)
- Diode Test 1mA: @ 1.5V approx
- Continuity Test: Audible beep <50Ω
- Dimensions: 8.2×1.5×1.1” (208x38x29mm)
The Extech 381676A is a Pen Styled Multimeter with a Built in NCV detector. The 381676A features nine functions including AC/DC voltage to 600V, AC/DC Current to 200mA, Resistance, as well as Logic, Diode and Continuity tests. This meter has an easy to use rotary dial with alligator clips for one handed operation. Its convenient built in non-contact voltage detector allows for quick detection of live voltage. The 381676 comes complete with test leads, alligator clips, batteries and manual.
