Extech 380405 General-Purpose Accessory Kit – New

Description

Features:

• Durable construction
• Case may be grounded separately
• 3 binding posts permit isolated substitutions
• 5% Capacitance substitution from 100pF to 11,111µF
• Excellent for circuit development
• Five decade ranges of capacitance

Specifications:

• Capacitance ranges: 100pF to 11.111uF in 100pF steps
• Internal Residual Cap: 50pF maximum
• Voltage limit: 50VDC (non-polarized capacitors)
• Connection: Three (3) binding posts
• Accuracy: 5% (< =1uF: 1kHz test frequency; > 1uF: 100Hz test frequency)
• Operating conditions: Temperature: 32 to 122°F (0 to 50°C) / Humidity: < 80%RH

The Extech 380405 Capacitance Decade Box is very popular for product design testing and calibration because it can be substituted into a circuit and function in the place of any component with a standard value easily. Alternatively, it can be used to identify the best value for circuit operation then read that value from the switches. A capacitor of the size indicated by the decade box switches can then be put into the circuit.
