Description
Additional Features:
This product was DISCONTINUED on 4/15/2026, please let us know if you would like a refurbished LI-215A.
- Frequency range: 9 kHz or 0.009 MHz – 30 MHz
- Inductor uH: 250 and 50
- Current Rating Amps: 15
- EMI Test Specification: CISPR, EN
- Coils matched to application
- Air core coils
- Individually calibrated
The LISNs are intended for EMI conducted emissions testing. The Com-Power LI-215A was designed to test products according to FCC Part 15, EN and CISPR standards.The model LI-215A contains two networks enclosed in single RF shielded enclosure for single phase power configuration. Power to the LISN can be supplied by either AC or DC power source.
The LISN model Com-Power LI-215A is placed between the power source and EUT to stabilize line impedance, provide a 50 ohm RF connection, and block unwanted RF noise from the external power source. The Com-Power LI-215A uses air coils in the current path in order to avoid saturation due to high current. This model can handle up to 15 A. The bottom of the LISNs are unpainted for grounding purposes.
This model has a standard US socket on the front panel for EUT connection. The measurement port has a N type connector. The front panel also has a line selection switch for testing each line separately.
Com-Power recommends using a optional LIT-930 transient limiter to protect the spectrum analyzer or receiver input.
These LISN are calibrated to meet the CISPR 16-1-2, 2006, edition 1.2 and ANSI C63.4, 2009 requirements.The test data will supplied with each LISN.
