Chroma 19020 AC/DC Hipot Tester – Factory-Fresh New Unit

Description

Features:

• Test Modes – ACWV/DCWV/IR/Multi-channel
• Withstanding – 5 kV AC/10 mA, 6 kV DC/5 mA
• IR Range – 1M?~50G?
• IR Output Voltage – DC : 0.05~1kV
• 10 Channels
• OSC (Open/Short Check)
• Programmable V-output and limits
• Flashover detection
• Master/Slave control
• Standard RS-232/Handler/GPIB interfaces
• Large LCD panel
• Panel lock function

Chroma 19020 comes equipped with the world’s first sync hipot test function. One single unit can operate 10 channels simultaneously with synchronized output and measurements. Up to 10 units (master & slave) can be linked to have 100 channels in total. These can be grouped for output as to avoid creating voltage differences caused by adjacent tests as well as to improve productivity.

The 19020 also has powerful functions for Flashover detection and Open/Short Check. With several international patents, it is the best tool for regulatory electrical hipot tests as it not only offers reliable quality, but also creates a highly efficient test platform.
