B&K Precision 9205B Bench DC Power Supply – Unopened

Description

Features:

Multi-Range 60V/25A/600W DC Power Supply – NO GIPB

• Voltage: 0-60 V
• Current: 0-25 A
• Max Power: 600 W
• Multi-ranging operation
• High programming and readback resolution of 1 mV/0.1 mA
• Output timer function
• List mode programming
• Store and recall up to 72 instrument settings
• Standard USB (USBTMC-compliant), RS-232 interfaces supporting SCPI commands for remote control
• Remote sense

Multi-Range Programmable DC Power Supply, 600W, 60V, 25A, NO GPIB

The BK Precision 9205 can replace several supplies on your bench or in your rack. Unlike conventional supplies with fixed output ratings, this multi-range power supply automatically recalculates voltage and current limits for each setting, providing full output power in any Volt/Amp combination within the rated voltage and current limits.

For benchtop applications, this power supply provides a numerical keypad for direct data entry along with convenient cursors and analog-style knobs to quickly make incremental voltage or current changes. System integrators benefit from the standard USB (USBTMC-compliant), RS-232 interfaces supporting SCPI commands.
