B&K Precision 1670A DC Power Supply – Certified Used

Description

Additional Features:

• One variable 0 to 30 VDC, 3 A section
• One 12 VDC fixed section
• One 5 VDC fixed section

Specifications:

Constant Voltage Operation

• Line Regulation:  ≤0.05% + 10mV Main; ≤1% fixed output
• Load Regulation: ≤0.05% + 10mV; ≤1% fixed output
• Recovery Time 100μs
• Ripple & Noise: ≤5 mVrms
• Temperature Coefficient:  ≤300 ppm°C

Constant Current Operation

• Adjustable Current Range: 5% to 100% (Main)
• Line Regulation: ≤0.4% + 10 mA
• Load Regulation: ≤0.4% + 10 mA
• Ripple & Noise: ≤10 mA rms

Metering

• Display: 3-digit LCD
• Voltmeter Range: 0 to 12 VDC 0 to 5 VDC
• Voltmeter Resolution: 0.1 V
• Voltmeter Accuracy: ± (1% reading + 2 digit)
• Ampmeter Resolution 0.01 A
• Ammeter Accuracy: ± (1% reading + 2 digit)

General

• Overload Protection: Current limiting, Reverse polarity, overvoltage, Short circuit
• Power Requirements: 115/230 VAC, 50/60 Hz
• Power Consumption: 165 W
• Operating Temperature: 0 to 40°C ≤75% R.H.
• Storage Temperature: -15° to 70°C ≤85% R.H.
• Dimensions (H x W x D): 4.9” x 8.5” x 9.5″; (124 x 216 x 242 mm)

The BK Precision 1670A Triple-Output 30 VDC, 3A Digital Display Power Supply is ideal for general electronic servicing, school electronics labs, and powering up hobbyist’s projects.
