Description
Additional Features:
- Max Voltage: 60kVDC
- Max Current: 5mA continuous
- Polarity: Negitive with respect to ground
- AC Supply Voltage: 110-130 VAC
- 50/60 Hz, single phase, grounded
- 9 amps max
- Ripple: full load: 2%
The Biddle AVO 222060 is a two piece test set comprized of a control unit and high voltage unit. It is a stabilized dielectric test set for use in the field, shop or laboratory for measuring the electrical quantities of applied voltage and current flowing in specimens to which it is connected. Because it incorporates a stabilizing arrangement, measrement of variations in current with time are simplified. It has a very light-weight design for convenient transportation.
